VB-8203 Lutron Vibration Meter
| Usage/Application | Laboratory |
| Acceleration | 200 m/s^2. |
| Displacement | 2.0 mm |
| Display | LCD |
| Size | 200 x 68 x 30 mm. |
| Frequency | 10 Hz to 1 KHz |
| Weight | 253 gm |
| Display Size | 52 mm x 38 mm |
| Operating Humidity | Less than 80% RH |
| Operating Temperature | 0 to 5 deg C |
| Power Consumption | Approx DC 13 mA |
| Dimension | 200 x 68 x 30 mm |
| Resolution | 0.001 inch |
- Applications for industrial vibration monitoring: All industrial machinery vibrates. The level of vibration is a useful guide to machine condition. Poor balance, misalignment & looseness of the structure will cause the vibration level increase, it is a sure sign that the maintenance is needed.
- Frequency range 10 Hz - 1 kHz, sensitivity relative meet ISO 2954.
- Professional vibration meter supply with vibration sensor & magnetic base, full set.
- Metric & Imperial display unit.
- Acceleration, Velocity, Displacement measurement.
- RMS, Peak value, Max. hold measurement.
- Wide frequency range.
- Data hold button to freeze the desired reading
- Memory function to record maximum and minimum reading with recall.
- Separate vibration probe with magnetic base, easy operation.
- RS232 computer interface.
- Data Logger.
- Optional data acquisition software.
- Optional data logger ( data collection ) software.
- Super large LCD display with bar graph indicator.
- Microcomputer circuit, high performance.
- Auto shut off saves battery life.
- Built-in low battery indicator.
- Heavy duty & compact housing case.
- Complete set with the hard carrying case.
